SCREEN SIZE	43"
CHIPSET-TV solution	P75-2842V6.2
MARKET AREA	ATV+DTV ( DVB-T/C/T2/S2)
Panel Type, TFT LCD with LED Backlight	YES
Panel Frame Rate	60hz
Panel Aspect Ratio	16:09
Panel Pixel Number	1920*1080
Panel Brightness (Type) (unit: cd/m2)	220(±10％）
Panel Contast (TYP)	1200:1
Panel Viewing Angle(H/R,CR>=10) (Type) ,H:178°,V:178°	H:178°, V:178°
Panel Response Time (GTG）	8ms
Panel Display Colors	1.07B
Terminals Cable/Antenna Input	*2
Terminals HDMI™ / Audio In	*3
Terminals VGA IN	*1
Terminals AV IN	*1
Terminals Headphone Output	*1
Terminals USB	*2
Terminals COAX	*1
Terminals RJ45	*1
ATV VIDEO SYSTEM	PAL,/SEACM
ATV SOUND SYSTEM	BG, DK, I
ATV RECEIVE CHANNEL	200CH
DVB-C/T/T2/S/S2-Input Impedance	75Ω
DVB-C/T/T2/S/S2-Channel Bandwidth	TBD
DVB-C/T/T2/S/S2-Basic Functions	EPG, NICAM/A2, TELETEXT
DVB-C/T/T2/S/S2-Max Storage Channels	"1000CH(DVB-T/C/T2) 4000CH(DVB-S/S2)"
Audio Input PC Audio	TBD
Audio Input CVBS	1.0Vp-p +/-5%
Audio Input Component	TBD
Audio Output Earphone	TBD
Audio Output COAX	TBD
Audio Output power	8Ω/8W *2
VIDEO INPUT CVBS	1.0Vp-p +/-5%
VIDEO INPUT YPbPr / YCbCr	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
VIDEO INPUT HDMI	480i、480p、576i、576p、720p、1080i、1080p
VIDEO INPUT	HDMI:1.4
POWER TO PANEL	12V
USB FUNCTION-software upgrade, multimedia play	YES
Dimension-Set Size (W*D*H) with Stand / mm	970*208*609
Dimension-Set Size (W*D*H) without Stand / mm	970*77*571
Loading 40HQ:	910
Loading 40GP:	684
Loading 20GP:	336
POWER CONSUMPTION	75W
OSD LANGUAGE	English, French, Arabic, Russian, Farsi
VIDEO INPUT PC-RGB	Up to 1920*1080@60HZ
Power Supply	～110-240V
